Whether you are looking to prepare the soil to get your crop in the ground or you are ready to get your crop out of the field, John Deere has the equipment to get the job done. John Deere’s history with tillage equipment dates back to when John Deere invented the self-scouring steel plow. Since then, they have continued to lead the way with new larger and more innovative designs. Our tillage equipment includes spring, fall, and year-round options.
| Working width |
|---|
| 6.1 to 13.72 m / 20 to 45 ft |
| Transport width |
| 4.37 to 5.87 m / 14.33 to 19.25 ft |
| Minimum recommended tractor horsepower |
| 0.75 kilowatt per 0.305 meter of working width / One horsepower per foot of working width |
| Working width |
|---|
| 2.3 m 7.5 ft / 2.7 m 9 ft / 3.05 m 10 ft / 3.8 m 12.5 ft / 4.6 m 15 ft / 5.3 m 17.5 ft / 6.8 m 22.5 ft |
| Transport width |
| 3.05 m 10 ft / 4.1 m 13.5 ft / 5 m 16.5 ft / 6.7 m 22 ft / 4.7 m 15.5 ft |
| Operating depth |
| Maximum / 40.6 cm / 16 in. / |
| Working widths - 3-section |
|---|
| Option 1: 7.77 m (25.5 ft) / Option 2: 8.99 m (29.5 ft) / Option 3: 9.6 m (31.5 ft) / Option 4: 10.21 m (33.5 ft) / Option 5: 10.82 m (35.5 ft) / Option 6: 12.95 m (42.5 ft) |
| Rigid frame - 3-section |
| Option 1: 4.75 m (15.58 ft) / Option 2: 4.75 m (15.58 ft) / Option 3: 4.75 m (15.58 ft) / Option 4: 4.82 m (15.83 ft) / Option 5: 4.85 m (15.92 ft) / Option 6: 5.33 m (17.5 ft) |
| Transport height (without rear harrow) - 3-section |
| Option 1: 3.43 m (11.25 ft) / Option 2: 3.94 m (12.92 ft) / Option 3: 4.22 m (13.83 ft) / Option 4: 4.52 m (14.83 ft) / Option 5: 4.9 m (16.08 ft) / Option 6: 4.22 m (13.83 ft) |
| Working widths - 3-section |
|---|
| Option 1: 7.16 m (23.5 ft) / Option 2: 7.77 m (25.5 ft) / Option 3: 8.38 m (27.5 ft) / Option 4: 8.99 m (29.5 ft) / Option 5: 9.6 m (31.5 ft) / Option 6: 10.2 m (33.5 ft) / Option 7: 10.85 m (35.5 ft) / Option 8: Low Transport - 11.73 m (38.5 ft) / Option 9: Low Transport - 13.25 m (43.5 ft) |
| Rigid frame - 3-section |
| Option 1: 4.19 m (13.75 ft) / Option 2: 4.19 m (13.75 ft) / Option 3: 4.19 m (13.75 ft) / Option 4: 4.19 m (13.75 ft) / Option 5: 4.78 m (15.67 ft) / Option 6: 4.78 m (15.67 ft) / Option 7: 4.8 m (15.75 ft) / Option 8: 4.27 m (14 ft) / Option 9: 5.45 m (18 ft) |
| Transport height (without rear harrow) - 3-section |
| Option 1: 3.43 m (11.25 ft) / Option 2: 3.66 m (12 ft) / Option 3: 3.94 m (12.92 ft) / Option 4: 4.22 m (13.83 ft) / Option 5: 4.24 m (13.92 ft) / Option 6: 4.52 m (14.83 ft) / Option 7: 4.8 m (15.75 ft) / Option 8: 4.11 m (13.5 ft) / Option 9: 4.37 m (14.33 ft) |
| Operating depth |
|---|
| Maximum / 406 to 559 mm / 16 to 22 in. / |
| Horsepower per standard |
| With 3-point hitch: 53 to 165 engine kW / 39.5 to 123 engine hp |
| Working widths - 3-section |
|---|
| Option 1: 6.63 m / 21.75 ft / Option 2: 7.54 m / 24.75 ft / Option 3: 8.46 m / 27.75 ft / Option 4: 9.37 m / 30.75 ft / Option 5: 10.29 m / 33.75 ft |
| Transport width (without rear harrow) - 3-section |
| Option 1: 4.32 m / 14.17 ft / Option 2: 4.27 m / 14 ft / Option 3: 4.44 m / 14.58 ft / Option 4: 4.5 m / 14.75 ft / Option 5: 4.72 m / 14.5 ft |
| Transport height (without rear harrow) - 3-section |
| Option 1: 3.12 m / 10.25 ft / Option 2: 3.76 m / 12.33 ft / Option 3: 4.04 m / 13.25 ft / Option 4: 4.62 m / 15.17 ft / Option 5: 5.08 m / 16.67 ft |
| Working widths - Rigid frame |
|---|
| Option 1 / 3.56 to 5.28 m / 11.67 to 17.33 ft / 3.05 to 5.49 m / 10 to 18 ft / |
| Maximum depth |
| Rigid, TruPosition: max: 20.32 cm / 8 in. / Spring-reset TruDepth: max: 30.5 cm / 12 in. |
| Miles per hour |
| 8 to 11.3 km/h / 5 to 7 mph |
| Working width |
|---|
| 3.8-8.4 m / 12.5-27.5 ft |
| Transport width |
| With furrow filler attachment: 5.2-5.6 m / 16.9-18.4 ft |
| Maximum operating depth |
| 40.6 cm / 16 in. |
| Working width |
|---|
| Option 1: 4.3 m / 14 ft / Option 2: 5.5 m / 18 ft / Option 3: 5.5 m / Option 4: 6.7 m / 22 ft / Option 5: 7.9 m / 26 ft |
| Transport width |
| Option 1: Individual blades: 6.1 m 19.9 ft / Disk gangs: 5.7 m 18.8 ft / Option 2: Individual blades: 6.9 m 22.5 ft / Disk gangs: 6.9 m 22.5 ft / Option 3: Individual blades: 5.7 m 18.8 ft / Disk gangs: 5.8 m 19.1 ft / Option 4: Individual blades: 5.6 m 18.3 ft / Disk gangs: 5.7 m 18.7 ft / Option 5: Individual blades: 5.6 m 18.3 ft / Disk gangs: 5.6 m 18.3 ft |
| Maximum operating depth |
| 40.6 cm / 16 in. |
| Plowing depth |
|---|
| 305 mm / 12 in. / 356 mm / 14 in. |
| Transport width -Rigid frame |
|---|
| / |
| Working widths - Rigid frame |
| / |
| Working width 2-bar |
|---|
| 1.9-3.43 m / 6.25-11.25 ft |
| Working width 3-bar |
| 3.43-6.48 m / 11.25-21.25 ft |
| Transport width |
| 2.1-4.4 m / 7-14.33 ft |
| Working width |
|---|
| Option 1: 2.5 m / 8.33 ft / Option 2: 3.2 m / 10.42 ft / Option 3: 3.8 m / 12.5 ft |
| Transport width |
| Option 1: 2.1 m / 7 ft / Option 2: 2.1 m / Option 3: 2.1 m |
| Operating depth |
| Maximum / 58.4 cm / 23 in. / |
| Working width |
|---|
| Option 1: 2.5 m, 8.33 ft / Option 2: 3.2 m, 10.42 ft / Option 3: 3.8 m, 12.5 ft / Option 4: 3.6 m, 11.67 ft / Option 5: 4.44 m, 14.58 ft / Option 6: 5.3 m, 17.5 ft / Option 7: 4.6 m, 15 ft / Option 8: 5.72 m, 18.75 ft / Option 9: 6.9 m, 22.5 ft / Option 10: 5.59 m, 18.33 ft |
| Transport width |
| Option 1: 4.2 m, 13.75 ft / Option 2: 4.2 m, 13.75 ft / Option 3: 4.2 m, 13.75 ft / Option 4: 5.36 m, 17.58 ft / Option 5: 5.36 m, 17.58 ft / Option 6: 5.36 m, 17.58 ft / Option 7: 5.36 m, 17.58 ft; Or with extensions: 6.91 m, 22.67 ft / Option 8: 5.36 m, 17.58 ft; Or with extensions: 6.91 m, 22.67 ft / Option 9: 5.36 m, 17.58 ft; Or with extensions: 6.91 m, 22.67 ft / Option 10: 5.36 m, 17.58 ft; Or with extensions: 6.91 m, 22.67 ft |
| Operating depth |
| Maximum / 58.4 cm / 23 in. / |
| Plowing depth |
|---|
| 35.6 cm / 14 in. |
| Horsepower required - Option 1 |
| 2-bottom: 37.3-52.2 kW / 50-70 hp |
| Plowing depth |
|---|
| 35.6 cm / 14 in. |
| Horsepower required - Option 1 |
| 5-bottom: 96.9-123 kW / 130-165 hp |
