Transmission type | Hydrostatic with 3 hydraulic wheel motors |
Travel Speed (forward or reverse) | Reverse: 6 km/h / 4 mph / Forward: 0-10 mph / 16 km/h |
Engine type | Air-cooled |
Transmission type | Hydrostatic with 3 hydraulic wheel motors |
Travel Speed (forward or reverse) | Reverse: 6 km/h / 4 mph / Forward: 0-10 mph / 16 km/h |
Engine type | Air-cooled |
Wide high-flotation tires provide low ground compaction.
The 47-in. (119-cm) wheelbase enables a tight turning radius.
A heavy-duty air filter is standard equipment on the 1200A Bunker and Field Rake. Featuring a cyclone design, this dual element filter can eject 90 percent to 95 percent of dust particles before they reach the paper element core. This reduces overall maintenance costs through less cleaning and replacement.
The forward and reverse foot pedals provide ease of identification and operation. The forward pedal is larger than the reverse pedal and provides good clearance for the operator's foot. This is the same two-pedal design used on the John Deere 2500A Riding Greens Mower.
Raising the hinged rear fiberglass body cowling exposes the 16-hp*(11.9-kW), 479-cc air-cooled, overhead valve engine:
*At 3600 rpm. Engine manufacturer gross power per SAE J1940. Tested in accordance with SAE J1995. The engine hp and torque information are provided by the engine manufacturer for comparison purposes only. Actual operating hp and torque will be less. Refer to the engine manufacturerâs website for additional information.
The hydrostatic 3WD system has variable speed for excellent pulling and pushing power.
Instruments and electronic controls are positioned for easy reach and visibility:
Key Specs | |
Transmission type | Hydrostatic with 3 hydraulic wheel motors |
Travel Speed (forward or reverse) | Reverse: 6 km/h 4 mph Forward: 0-10 mph 16 km/h |
Engine type | Air-cooled |
Attachments | |
Rake | |
Cultivator | |
Front blade | |
60-in. aluminum front blade | |
Articulating front-mount core-removal blade | |
Wide- and narrow-interval scarifier tines attachment | |
Mid-mount 64.5-in. (164.9 mm) scraper blade attachment | |
Rear-mounted 60-in. field finisher | |
Hydraulic pump package | |
Dimensions | |
Ground clearance @ rake attachment | 241 mm 9.5 in. |
Width | 187 cm 73.5 in. |
Height | 114 cm 45 in. |
Length | 216 cm 85 in. |
Wheelbase | 1193.8 mm 47 in. |
Turning radius | Zero |
Weight (approx.) | 404 kg 890 lb |
Electrical System | |
Battery | 500 CCA 12 V |
Starter | Electric |
Ignition | Transistor type |
Light kit | Available |
Engine | |
Displacement | 480 cc 29.3 cu in. |
Compression ratio | 8.5:1 |
Lubrication | Full pressure |
Oil capacity | Without filter: 1.4 L 1.5 U.S. qt |
Oil filter | Standard |
Spark arrester muffler | Standard |
Idle speed | Low speed: 1,750 rpm fast idle speed (low load): 3,100 rpm |
Fuel System | |
Tank capacity | 14.8 L 3.9 U.S. gal. |
Fuel pump | Diaphragm-type |
Fuel required | Unleaded gasoline |
Sound Levels | |
Operator ear | 76 dBA |
Measuring standard | ISO 11201 |
Tires | |
Front | One 22x11x8 NHS 34.5 kPa 5 psi |
Rear | Two 22x11x8 NHS 34.5 kPa 5 psi |
Transmission | |
Type | Hydrostatic with 3 hydraulic wheel motors |
Fluid capacity | 12.2 L 12.9 U.S. qt |
Travel Speed | |
R | R |
