John Deere 1023E

Large seat cover

• Cushioned seat for extra comfort
• Fabric coated for maximum water resistance and repellency
• Elastic cord locks around safety sign on seat back
• Elastic cord in bottom hem for a custom fit
• Handy zippered storage case

Ordering information

Please contact your local John Deere dealer for availability and pricing information.

Large seat cover
Order number: LP95233

Ballast box with extension

The ballast box can be used to carry additional ballast for greater tractor stability.

A 23-cm (9-in.) high extension can be added to ballast box for even greater capacity.

The hitch utilizes a standard Category 1 configuration for connection to the tractor Category 1 hitch.

A bushing kit is required for the ballast box to be used with the iMatch™ Quick-Hitch.

The ballast box extension is only available through Parts; it is not a factory option.

Ballast box

Ballast box with 3E Tractor

A ballast box can be used to carry additional ballast for greater tractor stability.

A 23-cm (9-in.) high extension can be added to ballast box for even greater capacity.

Ballast box extension

The hitch utilizes a standard Category 1 configuration for connection to the tractor Category 1 hitch.

A bushing kit is required for the ballast box to be used with the iMatch™ Quick-Hitch.

Third SCV kit

Includes single-lever control, hydraulic lines, and rear-mounted couplers with one set of outlets.

• Allows using third spool on SCV
• Provides a single set of rear SCV outlets for added versatility

Rear-hydraulic outlet kit

The rear-hydraulic outlet kit routes hydraulic power from dual mid-selective control valves to two sets of couplers at the rear of tractor.

Shown on 4000 TEN Series Tractor

ROPS warning-light brush guards protect turn signal/warning lights from damage caused by low branches on trees.

For open-station tractors only.

Two guards included in each kit.

The forward-lighting kit provides extra visibility when working in dark conditions. Lights attach to the brush guards located on the rollover protective structure (ROPS). Each kit contains two lights.

NOTE: Requires BLV10400 warning light brush guard kit and LVB26026 light kit harness. Not compatible with LVB25547 rear work light kit (1023E).

NOTE: Requires BLV10400 warning light brush guard kit. Not compatible with LVB25547 rear work light kit (1025R, 2025R, 2032R, 2038R, 3025E, 3032E, 3038E, 4105, 4044M, 4052M, 4066M).

NOTE: Requires BLV10620 premium warning light brush guard kit. Not compatible with LVB25547 rear work light kit (3033R, 3039R, 3046R, 4044R, 4052R, 4066R).

Rear work light

This kit provides light to the rear of the tractor for evening work.

For open-station tractors only, this kit contains individual light.

Allow 30 minutes to install.

NOTE: Kit includes one rear light.

NOTE: Both the rear- and forward-work lights are compatible together and with the light-brush guard kits. The light kit contains a two-to-four pigtail that plugs into the main harness, as if only plugging one set of lights, providing two sets of plugs to use for forward and rear-work lights. The forward light is installed on top of the brush guard, and the rear light is installed inside the ROPS using the bolt holding the light and brush guard on.

NOTE: For 102E3 and 1026R Tractors – kit interference during backhoe operations (mounted inside ROPS) – use LVB25546 forward-light kit as an alternative.

 Rollover protective structure (ROPS) mounted LED work lights

An optional LED work light kit is available for all open-station compact utility tractors. These lights provide extra visibility when working in dark conditions and have 180-degree rotation to face forward or backward. The kit contains two lights and the mounting hardware required for installation.

This lighting kit is mounted to the warning light brush guard kit, which is mounted to the ROPS and requires attachment BLV10400 for installation.

The halogen work light kit attachment is still available (LVB25546).

Light wire harness required to use with LVB25547 rear-work light kit and LVB25546 forward-lighting kit on 1023E Tractors.

iMatch quick-coupler bushing kit

This bushing kit is for use with Category 1 implements (ballast box) to make them function correctly with the iMatch Quick-Hitch.

iMatch Quick-Hitch (LVB25255)

iMatch Quick-Hitch with rotary cutter hookup (LVB25255)

iMatch Quick-Hitch (LVB25976)

iMatch Quick-Hitch with rotary cutter hookup (LVB25976)

One of the greatest customer concerns involves difficulty in attaching tractor implements. John Deere has addressed this issue with the iMatch Quick-Hitch.

The iMatch Quick-Hitch provides easy hookup and a guaranteed fit for all Category 1 implements that are designed to meet the ASAE Category 1 Standard S278.6 for quick-attach hitches.

• All implements require a set of bushings in order for the attachment to fit and work properly with the iMatch Quick-Hitch. One set of bushings comes with the iMatch Quick-Hitch.

NOTE: In the picture above, you see the bushing set. These bushings allow the hooks on the iMatch and the pins on the implement to fit together properly. All other implements (box blades, tillers, rear blades, etc.) will require a set of bushings to enlarge the pin to fit with the iMatch hooks. Bushings of different lengths can be found in the parts system or through a bushing supplier (see dimensions below).

• Upper bushing
  • Inside diameter: 0.76-0.77 in.
  • Outside diameter: 1.24-1.25 in.

• Lower bushings
  • Inside diameter: 0.88 to 0.89 in.
  • Outside diameter: 1.43 to 1.44 in.

iMatch Quick-Hitch bushing

Ordering information

Customers, please contact your local John Deere dealer for availability and pricing information.

iMatch Quick-Hitch Bushings
Order number: LP19969

One or two 23-kg (50-lb) cast-iron weights may be installed on each rear wheel to provide extra traction and stability.

• Made of durable cast iron and painted John Deere yellow
• May be installed with wheel in either the narrow or wide position
• To stack the weights and install two on a wheel, two 1/2x8-in. bolts are required per wheel (not furnished)

23-kg (50-lb) plastic-shell rear-wheel weight

One 23-kg (50-lb) plastic-shell rear-wheel weight may be installed on each rear wheel to provide extra traction and stability.

• Outer shell made of tough polyethylene plastic
• Filled with a heavy granular material that contains a high iron percentage
• A bonding substance is added to hold the material together so that it will remain intact even if shell is damaged

Multiple stacking is not recommended.

Overall width of the tractor will be increased by approximately 5 cm (2 in.) when weights are installed.

Schematic of weight installed on wheel

Weights are packaged one per carton, with necessary hardware for installation on a wheel, in either the narrow or wide position.

70-lb (32-kg) cast-iron starter weight

Starter weight with 50-lb (22.7-kg) cast-iron weight

70-lb (32-kg) cast-iron starter weights can be bolted to the outside of the rear wheels for ballast.

Additional 50-lb (22.7-kg) cast-iron wheel weights may be bolted to the starter weight.

NOTES:

1. For 26-in. (660-mm) tire and rim only.

2. Starter weight not for use on all-wheel-steer tractors.

3. X700 Special Edition Tractors (model year 2012 and prior) and X738, X739, and X758 Signature Series Tractors require a BM21497 wheel weight adapter ring on each rear wheel on which weights are to be installed.

NOTE: Plastic rear-wheel weight comes with necessary hardware for installation.

23-kg (50-lb) cast-iron wheel weights

For 23-kg (50-lb) cast-iron wheel weights on 26x12-in. rear tyres:

NOTE: Order two sets for both sides of the tractor.

33-kg (72-lb) starter cast-iron wheel weight

For 33-kg (72-lb) starter cast-iron wheel weight on 26x12-in. rear tyres:

NOTE: Order two sets for both sides of the tractor.

33-kg (72-lb) starter and 23-kg (50-lb) cast-iron weight(s)

For 33-kg (72-lb) starter and 23-kg (50-lb) cast-iron weight(s):

NOTE: Order two sets for both sides of the tractor

NOTE: Plastic rear-wheel weight comes with necessary hardware for installation.

23-kg (50-lb) cast-iron wheel weights

For 23-kg (50-lb) cast-iron wheel weights on 26x12-in. rear tyres:

NOTE: Order two sets for both sides of the tractor.

33-kg (72-lb) starter cast-iron wheel weight

For 33-kg (72-lb) starter cast-iron wheel weight on 26x12-in. rear tyres:

NOTE: Order two sets for both sides of the tractor.

33-kg (72-lb) starter and 23-kg (50-lb) cast-iron weight(s)

For 33-kg (72-lb) starter and 23-kg (50-lb) cast-iron weight(s):

NOTE: Order two sets for both sides of the tractor

NOTE: Plastic rear-wheel weight comes with necessary hardware for installation.

23-kg (50-lb) cast-iron wheel weights

For 23-kg (50-lb) cast-iron wheel weights on 26x12-in. rear tyres:

NOTE: Order two sets for both sides of the tractor.

33-kg (72-lb) starter cast-iron wheel weight

For 33-kg (72-lb) starter cast-iron wheel weight on 26x12-in. rear tyres:

NOTE: Order two sets for both sides of the tractor.

33-kg (72-lb) starter and 23-kg (50-lb) cast-iron weight(s)

For 33-kg (72-lb) starter and 23-kg (50-lb) cast-iron weight(s):

NOTE: Order two sets for both sides of the tractor

42-lb (19-kg) Quik-Tatch weight

42-lb (19-kg) weights and optional mounting bracket

The 42-lb (19-kg) Quik-Tatch can be used to counterbalance a heavy front or rear attachment and/or provide greater stability, especially when operating on hills.

This weight is constructed of cast iron and weighs approximately 42 lb (19 kg).

Some vehicles have built-in front and/or rear weight brackets to hang the weights on; others require a weight bracket that must be ordered separately.

X400/X500 Heavy-Duty Garden Tractors and X700 Series Tractors require the following parts when weights are installed on the front of the tractor:

• One  M147986 weight retaining rod (Parts)
• Two  M40461 spring clip (Parts)
