| Model | Number of Tines | Weight | Width |
|---|---|---|---|
|
AF60 Ag Fork |
6 |
370 lb. (168 kg) |
59 in. (1500 mm) |
|
AF66 Ag Fork |
7 |
395 lb. (179 kg) |
65 in. (1652 mm) |
|
AF72 Ag Fork |
7 |
435 lb. (197 kg) |
71 in. (1804 mm) |
|
AF78 Ag Fork |
8 |
445 lb. (202 kg) |
77 in. (1956 mm) |
| Model | Width | Maximum Root Ball | Fork Opening (Parallel) |
|---|---|---|---|
|
NF44 Nursery Fork |
1194 mm (47 in.) |
1118 mm (44 in.) |
457 mm (18 in.) |
| Model | Frame Width (with steps) | Fork Thickness | Pallet Fork Rating (pair of tines) |
|---|---|---|---|
|
Rail |
1353 mm (53.3 in.) |
35 mm (1.4 in.) |
1700 kg (3,750 lb.) |
|
Heavy Duty |
1723 mm (67.8 in.) |
45 mm (1.78 in.) |
2270 kg (5,000 lb.) |
|
Severe Duty for CWLs |
N/A |
50 mm (2 in.) |
4000 kg (8,800 lb.) |
|
Severe Duty PF45 |
1380 mm (54 in.) |
50 mm (2 in.) |
4000 kg (8,800 lb.) |
|
Severe Duty PF60 |
1730 mm (68 in.) |
50 mm (2 in.) |
4000 kg (8,800 lb.) |
| Model | Weight | NUMBER OF MAIN TINES | TINE CAPACITY |
|---|---|---|---|
|
AB21 Bale Spears |
66 kg (145 lb.) |
1 main tine |
907 kg (2,000 lb.) |
|
AB31 Bale Spears |
91 kg (200 lb.) |
1 main tine |
1361 kg (3,000 lb.) |
|
AB32 Bale Spears |
70 kg (155 lb.) |
2 main tines |
1361 kg (3,000 lb.) |
|
AB42 Bale Spears |
109 kg (240 lb.) |
2 main tines |
1814 kg (4,000 lb.) |
|
AB43 Bale Spears |
102 kg (225 lb.) |
3 main tines |
1814 kg (4,000 lb.) |
|
Square |
171 kg (375 lb.) |
-- |
-- |
