John Deere 2410C

DEBUG Ind: Agriculture, Cat: Implements, SubCat: Sprayers and Application, SubSubCat:
Feature Overview
John Deere 2410C
  • Tru-Depth™ conventional standard or parabolic chisel
  • GreenStar™ Rate Controller
  • John Deere AccuDepth™
  • Widths up to 62.5 ft. (19 m)
Get Financed
Request a Demo/Quote

*Inventory shortages may cause extended delivery dates

*This price does not include attachments and accesories

Value Your Trade
Feature Overview
John Deere 2410C
  • Tru-Depth™ conventional standard or parabolic chisel
  • GreenStar™ Rate Controller
  • John Deere AccuDepth™
  • Widths up to 62.5 ft. (19 m)
Get Financed
Request a Demo/Quote

*Inventory shortages may cause extended delivery dates

*This price does not include attachments and accesories

Value Your Trade

Variety of models and sizes available

2410C Nutrient Applicator2410C Nutrient Applicator

The 2410C Nutrient Applicator is available in five machine configurations:

  • 19 row – 3.66-m (12-ft) centerframe, 5-section, 305-mm (30-in.) spacing
  • 21 row – 4.57-m (15-ft) centerframe, 5-section, 305-mm (30-in.) spacing
  • 23 row – 4.57-m (15-ft) centerframe, 5-section, 305-mm (30-in.) spacing
  • 24 row – 4.57-m (15-ft) centerframe, 5-section, 305-mm (30-in.) spacing
  • 25 row – 4.57-m (15-ft) centerframe, 5-section, 305-mm (30-in.) spacing



Working width

Transport width

Transport height

19 row

14.5 m (47 ft, 6 in.)

6.0 m (19 ft, 8 in.)

4.30 m (14 ft, 1 in.)

21 row

16.0 m (52 ft, 6 in.)

6.60 m (21 ft, 8 in.)

4.70 m (15 ft, 5 in.)

23 row

17.5 m (57 ft, 6 in.)

6.60 m (21 ft, 8 in.)

5.0 m (16 ft, 5 in.)

24 row

18.3 m (60 ft)

6.60 m (21 ft, 8 in.)

5.0 m (16 ft, 5 in.)

25 row

19.1 m (62 ft, 6 in.)

6.60 m (21 ft, 8 in.)

5.0 m (16 ft, 5 in.)


The 19.1-m (62-ft, 6-in.) 2410C Nutrient Applicator delivers a 47 percent increase in productivity over the largest 13.0-m (42-ft, 6 in.) John Deere 2510C Conventional Applicator.


The five individual frame sections can be adjusted independently of each other. The operator can tailor the depth setting of individual sections to ensure proper product sealing and fertilizer placement even in compressed wheel track areas and varying field conditions.

The 2410C Nutrient Applicator is designed for precise and accurate depth control. AccuDepth©Â comes as standard equipment or single-point depth control is available as an option. Both provide accurate depth control to ensure exact nutrient placement and best utilize tractor horsepower.

AccuDepth on 2630 displayAccuDepth on 2630 display

With AccuDepth, these adjustments can be done on-the-go, increasing productivity and making the day easier for operators. AccuDepth provides accurate and precise depth control by the use of individual wheel sensors and electronic circuitry to perform tasks of leveling and depth measurements. Accurate depth is displayed to the nearest 2.5 mm (1/10 in.).

Single-point depth controlSingle-point depth control

The field-proven single-point depth control offers the producer one easy, front-mounted crank to dial in their depth control for the entire implement. From one location, this adjustment is easily and quickly completed.

The Tru-Depth™ heavy-duty cast standards on the 2410C Nutrient Applicators are designed for precise and accurate nutrient placement and offer 567 kg (1250 lb) of trip force to allow for faster operating speeds. The conventional standard comes as base equipment and the parabolic chisel standard is available as an option.

Conventional heavy-duty Tru-Depth standardConventional heavy-duty Tru-Depth standard

The Tru-Depth conventional heavy-duty cast standard allows for application from 100 mm (4 in.) to 250 mm (10 in.) deep. With a trip height of 279 mm (11 in.), the standard is able to handle field obstacles and reset back to the operating depth with no shear bolt replacement. This reduces downtime spent replacing shear bolts which leads to increased productivity.

Heavy-duty cast Tru-Depth standardHeavy-duty cast Tru-Depth standard

The Tru-Depth heavy-duty cast chisel standard allows operators to perform tillage up to 305 mm (12 in.) deep and gives them the ability to perform nutrient application and tillage in one pass. The standard is designed to mix and bury residue to promote decomposition and encourage faster soil warming.

Chisel on left, conventional on rightChisel on left, conventional on right

Adjustable closing disks operating in worked groundAdjustable closing disks operating in worked ground

The closing disk system is standard equipment on the conventional models and is not available on the chisel models. As the nutrient knife places anhydrous, closing disks reduce soil disturbance while bringing the soil back for proper sealing. Soil types, moisture, and residue levels can greatly affect the amount and consistency of the soil that is brought back in. The closing disks on the 2410C can be adjusted from a narrow setting of 220 mm (8.8 in.) apart to the widest setting of 430 mm (17 in.) apart for industry leading adjustability.


The closing disk system on the 2410C requires no tools for adjustability. Fore-aft and lateral settings are pin adjustable and have variable down force. This makes for quick, easy adjustments that allow for customizable settings to meet field finish preferences. For increased productivity and ease of serviceability, there are no grease zerks on the closing disks assembly.


The 460-mm (18-in.) concave notched blades close the slot and seal the anhydrous in the soil. The closing disks are designed with down-pressure springs built in, which limits bounce in rough field conditions. The closing arms have been engineered to flex as large obstructions (clods/rocks/etc.) flow between the knife and the blade. Independent up and down travel arms are key to the nearly plug-free closing disk. This allows one machine to operate in any soil type and eliminates the need to have multiple disk sealer attachments along with labor required to change them out.

Pin-adjust closing disk Pin-adjust closing disk

3.4-m (134-in.) four-rank frame3.4-m (134-in.) four-rank frame

The four-rank frame design of the 2410C has provided unmatched reliability to John Deere operators for over 10 years and a countless amount of acres. With operators requiring faster working speeds out of larger implements, machines require thicker frame tubes, additional diagonal bracing, and frame gussets to endure 600 engine horsepower tractors.


The frame stretches 3.40 m (134 in.) front-to-back, which allows for high levels of residue to easily flow through the staggered row units ensuring higher productivity and consistent nutrient placement. The large frame member sizes, tube-through-tube construction, and wheel module placement adds to the structural integrity, providing a stable front-to-rear and side-to-side operation.


The open frame design of the 2410C offers the ability to mount anhydrous distribution and nitrogen stabilizer systems in different locations throughout the bar based on user preference and convenience.


The ease of accessibility to the maintenance points of the machine is achieved through 1.1 m (44 in.) of underframe clearance. This enables the operator to save valuable time while experiencing less fatigue for routine maintenance and service.

Frame construction offers:
  • Consistent operating depth
  • Improved nutrient placement
  • Clear view of machine operation
  • Ease of serviceability
  • 10 degrees up flex and 15 degrees down flex

Walk-Over™ tandem wheelsWalk-Over™ tandem wheels

The wheel configuration of the 2410C provides increased performance with a total of 18 front castering and Walk-Over©Â tandem wheels. This allows for excellent depth accuracy for following the contour of the terrain and provides greater flotation and maneuverability.

The staggered wheel design provides additional room for residue flow, obstacles, and transport stability. Ultimately, this setup leads to precise nutrient placement, eliminating gas-out while achieving increased application speeds in varying field conditions.
The front castering wheels provide good stability at the front of the machine and facilitate excellent turning, reducing tire scuffing. The rear-mounted walking tandem wheels maintain a level frame for increased operating speeds over rough fields .

*Manufacturer's suggested price. MSRP may be different in California. Taxes, freight, setup, and delivery not included. Optional accessories and attachments not included. Equipment, models and prices may vary by dealer. Product options and accessories may not be available in all regions. The engine horsepower and torque information are provided by the engine manufacturer to be used for comparison purposes only. Actual operating horsepower and torque will be less. Refer to the engine manufacturer’s website for additional information. Offers valid in the United States. Prices in U.S. dollars.
