Belts-other - width | 17.8 cm / 7 in. |
Regular pickup - Bars | Four |
Regular pickup - Number of teeth | 96 |
Regular pickup - Tooth spacing | 6 cm / 2.6 in. |
*Inventory shortages may cause extended delivery dates
*This price does not include attachments and accesories
Belts-other - width | 17.8 cm / 7 in. |
Regular pickup - Bars | Four |
Regular pickup - Number of teeth | 96 |
Regular pickup - Tooth spacing | 6 cm / 2.6 in. |
*Inventory shortages may cause extended delivery dates
*This price does not include attachments and accesories
As the hay enters the forming chamber from the pickup, belts immediately turn the hay to form a tight, dense core.
Incoming hay then feeds between the bale and the lower gate roll. Hay is tightly compressed into smooth, dense layers as it enters the bale.
Chaffing is greatly reduced to prevent loss and retain hay quality in the bale.
The idler arm rises with bale growth, forcing oil from the hydraulic cylinder through a pressure-relief valve to maintain uniform bale density throughout the bale-forming process.
The 0 Series Round Baler family welcomes the first, John Deere, North-American built precutter. This feed system in front of these machines is the MegaWide HC2. The MegaWide Plus name is known as the industry-leading feed system since its introduction with the 7 Series Balers. John Deere continues that legacy with the 0 Series. Proven designs of the MegaWide were maintained and improvements were made to key components to gain significant capacity.
The MegaWide© HC2 will only be available in a precutter configuration (available on the 450M, 460M, 460R, 560M, and 560R models):
The MegaWide HC2 has the same 2.2-m (7.22-ft) MegaWide Plus pickup from the 9 Series. Dry hay and silage 0 Series configurations will also have the MegaWide Plus pickup.
Before the introduction of the MegaWide HC2 , the cam-clutch protection for the driveline was only available on the 9 Series Premium Balers. It is in the base for the MegaWide HC2 precutter configurations. This driveline pushes the limitations of the baler and the MegaWide HC2 system by offering the best machine protection John Deere can provide.
Another feature brought over from the 9 Series Premium Balers and being offered on the 0 Series is the grease banks. All daily greasing can be done from the ground in one central location.
The roller baffle on the MegaWide HC2 doubled in size from the MegaWide Plus from 10.2-cm (4-in.) to 20.3-cm (8-in.) diameter to allow for increased speeds and performance in larger windrows.
The 450M, 460M, 460R, 560M, and 560R Balers that can be configured with the MegaWide HC2 feed system will have the same flare-to-flare pickup width of 2.2 m (7.21 ft). This 2.2-m (7.21-ft), flare-to-flare, width on 1.22-m (4-ft) balers is only a feature of the MegaWide HC2 feed system.
The primary rotor is only available on the MegaWide HC2 and is located directly behind the MegaWide pickups.
Industry-exclusive, fast-pitch augers have been placed on the primary rotor to move dry hay and silage past the transition points to avoid plugging.
The secondary rotor is another component on the feed system that was re-designed from the MegaWide Plus feed system to handle the increased demands of the high-capacity system.
A third drive roll is another feature that will only be offered with the MegaWide HC2 feed system.
Drop floor ™ if the baler exceeds capacity and plugs, the MegaWide HC2 can lower the knife floor from the cab of the tractor to easily feed the plug into the chamber.
All MegaWide HC2 feed systems will have silage components to limit maintenance and prevent crop build up on belts.
All 0 Series Balers use alpha-numeric identifiers for the model names:
The MegaWide HC2 can be ordered on mid specification (M) and premium specification (R) balers.
R specification balers will have the premium pickup with improved internal components that are covered under the 2-year/12,000-bale premium warranty
M specification balers and pickups will not contain premium baler components ™ exception for this is the MegaWide HC2 feed system will have the premium cam clutch for the driveline and grease banks.
For more information about the model specifications, see the chart below:
Baler option | Applicable models |
E = Economy
|
440E and 450E |
M = Standard
|
450M, 460M, 550M*, and 560M |
R = Premium
|
460R and 560R |
*NOTE: The 550M is only available in dry hay and silage configurations.
New Holland, Roll-Belt, and CropCutter are trademarks of CNH Global N.V. and its subsidiaries.
Increased torque ™ the MegaWide HC2 feed system required an additional drive configuration to power the primary rotor and to meet the capacity goals.
MegaWide HC2 feed systems will not have the adjustable crank handle for the pickup.
John Deere's 178-mm (7-in.) wide diamond-tread design ensures fast bale starts and grips the bale to prevent slippage and reduce chaffing. The treads are self-cleaning to reduce carryover. The belts are staggered to reduce the loss of fine material and are closely spaced to contain the hay for fast, easy starts.
The belts enclose 91 percent of the bale width to reduce loss of fine material and retain hay quality.
The staggered belt roll design enables any loose hay under or behind the belts to be returned to the pickup and into the baler. This design helps to prevent buildup at the front of the baler, which could cause hay loss and belt or splice damage.
Every baler in the 0 Series Family uses DiamondTough belts. Belts are constructed using a patented triple-weave process of nylon and polyester materials.
They have the strength to handle heavy shock loads and help maintain consistent belt length.
The DiamondTough belts are more puncture and tear resistant than other belts on the market and provide improved belt life and reliability.
All of the 0 Series Balers use the plate-type fasteners.
This closed-loop design uses a plate fastener with pre-assembled rivets that lock the fasteners into the belt, providing a powerful vice-type grip on the belt.
Previous 9 Series models |
New 0 Series models |
|
449 | â | 440E |
459E | â | 450E |
459 | â | 450M |
459 Silage Special | ||
469 | â | 460M |
469 Silage Special | ||
469 Premium | â | 460R |
559 | â | 550M |
559 Silage Special | ||
569 | â | 560M |
569 Silage Special | ||
569 Premium | â | 560R |
Baler option | Applicable models |
E = Economy
|
440E and 450E |
M = Standard
|
450M, 460M, 550M*, and 560M |
R = Premium
|
460R and 560R |
*NOTE: The 550M Round Baler will only be available in dry hay and silage configurations.
0 Series Balers have implemented specification levels for all models in the baler lineup similar to what was done when the 459E was introduced. Pickup options will remain the same for the new models equivalent specification. The precutter pickups will have the same MegaWide© Plus pickups that will be offered in mid specification (M) or the premium specifications (R) balers.
The BaleTrak Pro monitor-controller is included with the automatic electric tie option and the Edge-to-Edge option on the 450E Baler. The monitor sounds an alarm for near-full, full, and oversized bales.
The audible level of the monitor can be adjusted.
On the 440E Round Baler with hydraulic double-twine option, the near-full bale size warning can be adjusted by moving the nut (1) in the slot to match harvest requirements.
The bale size on 450M, 450E with automatic electric tie, 550M, 460M, and 560M Round Balers can be adjusted from the operator's station with the BaleTrak© Pro monitor-controller by pressing symbol 2, then pushing the +/- symbol.
The 9 Series Round Balers came standard with an adjustable hitch and this feature will continue to be in base with the 0 Series Round Balers. This feature allows the hitch height to be adjusted to optimize crop-feeding performance. Due to the wide array of tractor tire sizes and drawbar heights, hitch adjustment may be necessary to get the proper feed opening of the baler. The adjustable hitch eliminates the need for the 51-mm (2-in.) thick tractor drawbar kit (AE57344) because it has a wider opening.
Benefits of the adjustable hitch:
All eight bolts must be used when adjusting the hitch. There are four different positions as shown below:
Also standard on all 0 Series Round Balers, except the 450E, is the drawbar flap. This helps to eliminate hay from getting caught on the hitch of the baler. The drawbar flap is designed to allow the operator to remove or attach the flap without having to unhook the baler from the tractor.
The gull wing doors from the 9 Series Premium Balers have been removed. All M- and R-specification 0 Series Balers will have the same stamped, steel door design.
Standard on premium round balers is a factory-installed grease bank. This allows the operator to only have to grease eight zerks (four on each side of the baler) for grease zerks that were hard to reach on previous models. The operator will still have to grease the driveline and some other components on the baler.
NOTE: The grease bank will also be found on all 0 Series precutter configuration balers, M and R specification.
The 460R Premium and 560R Premium offer the producer a third bale-shape sensor that can be turned on or off. This will allow the operator to make consistent, square-shouldered bales since they can now see how the center of their bales are forming.
The ISOBUS system offered on the premium round balers allows the operator to use the latest technology when baling. They can utilize their GreenStar© 2600, GreenStar 2630, GreenStar 1800, or certain R-Series CommandCenter displays as their baling monitor and can switch between tractors without having to take the display with them. All information for the baler is stored on the controller.
A two-year or 12,000-bale warranty comes standard on 460R Premium and 560R Premium Round Balers only. Please see full product warranty for more details.
A silage-configuration baler allows the producer to put up silage hay. A silage configuration machine does not offer a precutter. There are three major components to a silage configuration baler: a staggered roller-auger kit (1), a starter roll-scraper knife, and a screen (2). The powered auger sits above the staggered roll on the baler to help keep wet hay from traveling up the belts and reduce buildup on the roll. The screen is bolted on the front of the baler as a safety feature. The knife/scraper is mounted in front of the starter roll to help prevent wrapping of wet crop on the starter roll.
The silage kit is offered as a bundle for field installation if the baler is not ordered as a silage-configuration machine from the factory. Attachment BE32442 is for 1.22-m (4-ft) wide machines and BE32443 is for1.52-m (5-ft) wide machines.
Also offered is a high-moisture kit. This kit does not include the same components that are on the silage-configuration balers. It offers the starter roll-scraper knife but does not include the staggered roll-auger kit. Attachment BE23828 is for 1.22-m (4-ft) machines and BE23829 is for 1.52-m (5-ft) machines.
Base equipment on: 450M Silage, 550M Silage, 460M Silage, 560M Silage, 450M Precutter, 460M/R Precutter and 560M/R Precutter.
Auxiliary take-up rolls prevent belt crossover and flipping in wet conditions. This roll is base equipment on all silage and precutter configuration balers. It also comes with the bale ramp bundle on the 440E and 450E Balers.
The 0 Series Round Baler family welcomes the first, John Deere, North-American built precutter. This feed system in front of these machines is the MegaWide HC2. The MegaWide Plus name is known as the industry-leading feed system since its introduction with the 7 Series Balers. John Deere continues that legacy with the 0 Series. Proven designs of the MegaWide were maintained and improvements were made to key components to gain significant capacity.
The MegaWide© HC2 will only be available in a precutter configuration (available on the 450M, 460M, 460R, 560M, and 560R models):
The MegaWide HC2 has the same 2.2-m (7.22-ft) MegaWide Plus pickup from the 9 Series. Dry hay and silage 0 Series configurations will also have the MegaWide Plus pickup.
A MegaWide Plus pickup is available on 440E, 450M, 550M, and 560M Round Balers. It is base equipment on the 450M Silage, 550M Silage, 460M, 460M Silage, and 560M Silage Balers. The MegaWide Plus pickup is also incorporated into the new MegaWide High Capacity and Cutting (HC2) high-capacity precutter feed system.
0 Series Balers have implemented specification levels for all models in the baler lineup, similar to what was done when the 459E was introduced. Pickup options will remain the same for the new models equivalent specification. The precutter pickups will have the same MegaWide Plus pickups that will be offered in mid specification (M) or the premium specification (R) balers.
MegaWide Plus pickups make baling easier, especially in wide or windblown windrows, and increases productivity; more hay volume means more bales per hour.
Mega and MegaTough pickup teeth are base equipment:
The 1.2-m (4-ft) balers use a full-length, reinforced toothbar design.
The 1.5-m (5-ft) balers use a heavy, C-channel construction. The pickup toothbars are divided into two half-sections that mount to a center spider for increased strength and even crop feeding.
Available only on the MegaWide Plus pickup, the patented roller baffle is self-adjusting and produces smoother crop flow across the pickup. The roller also improves crop pickup in small windrows and prevents roll ahead of crop.
When combined with the MegaWide Plus pickup, this feeding system allows increased ground speed with less chance of plugging for increased productivity in all field conditions.
The MegaWide Plus pickup uses a rotor-feeding assembly, which mounts behind the pickup for smooth and even crop flow into the bale chamber.
Rotor strippers allow crop to be lifted from the rotor teeth into the chamber without cutting or wrapping the crop.
The MegaWide Plus pickups and spiral rotor are chain-driven for positive bale starts with cutout clutch protection. The pickup is being driven off the drive roll and bypasses the starter roll. This will allow for reduced wear and breakage of the starter roll chain.
Semi-pneumatic gauge wheels provide smooth ground gauging over uneven terrain and protection to the pickup.
The pickup float springs are positioned for excellent flotation.
The adjusting crank positions the pickup to the desired operating height to match crop or field conditions.
An optional hydraulic pickup lift cylinder is available as an attachment.
Key Specs | |
Belts-other - width | 17.8 cm 7 in. |
Bale forming | |
Density control | Hydraulic |
Bale size indication | Electronic display on monitor |
Key Specs | |
Regular pickup - Bars | Four |
Regular pickup - Number of teeth | 96 |
Regular pickup - Tooth spacing | 6 cm 2.6 in. |
MegaWide Plus pickup - Number of regular teeth | 120 |
MegaWide Plus pickup - Number of mega teeth | Eight |
High-capacity pickup - Number of middle teeth | 120 |
High-capacity pickup - Number of mega teeth | Eight |
Bale | |
Size | Diameter 81 - 183 cm 32 - 72 in. Width 157 cm 62 in. 1.5 x 1.8 m 5 x 6 ft |
Baler | |
Weight | Shipping dry - 3,393 kg 7,482 lb Shipping precutter - 4,239 kg 9,346 lb |
Length | Gate closed 371 cm 146 in. Gate open 475 cm 187 in. |
Height | Gate closed 279 cm 110 in. Gate open 368 cm 145 in. |
High-capacity pickup | |
Width | Inside 196 cm 77 in. Flare 221 cm 87 in. |
Bale forming | |
Belts-other | Number Eight Width 17.8 cm 7 in. Texture Diamond Tread friction surface belts DiamondTough, triple-weave, single-ply belts |
Regular pickup | |
Bars | Four |
Number of teeth | 96 |
Tooth spacing | 6 cm 2.6 in. |
Lift control | Adjustable height control |
High-capacity pickup | |
Gauge wheels | Semi-pneumatic |
Stripper diameter | 25.4 cm 10 in. |
MegaWide Plus pickup | |
Number of regular teeth | 120 |
High-capacity pickup | |
Number of mega teeth | Eight |
Driveline | |
Type | Constant-velocity (CV) |
High-capacity pickup | |
Number of middle teeth | 120 |
Wrapping system | |
Control | Automatic to preset to bale size |
Twine arms | Two |
Twine ball capacity | Eight |
Monitor | |
Monitor console for tractor | ISOBUS |
Gate closed | Symbol on monitor |
Bale forming | ISOBUS |
Bale size | Mechanical and digital |
Near full bale | Audible, adjustable alert |
Full bale | Audible, adjustable alert |
Twine arm position Indicator | Mechanical |
Auto wrap | Activates when bale reaches preset size |
Oversize bale | Yes, audible and mechanical alerts |
Tire size | |
Standard | Premium - XL high-flotation 21.5L-16.1, 8 PR |
Optional | With MegaWide Plus or MegaWide HC |
Driveline | |
Drive protection | Premium - cut out clutch |
PTO speed | 540 or 1,000 rpm |
PTO lockback collar on tractor hookup | Yes |
PTO 60-degree free rotation | Yes |
Tractor Requirements | |
Minimum PTO | Dry Hay and Silage - 56 kW 75 hp MegaWide HC kW 85 hp |
Hydraulic SCV valves | One tractor selective control valve (SCV) is required when baler is equipped with electric twine wrap. Two tractor SCVs are required when baler is equipped with hydraulic twine wrap. Three tractor SCVs are required when baler is equipped with hydraulic twine wrap and a hydraulic pickup lift. |
Additional information | |
Date collected | 14-February-2018 |
